Product Description
Technical Specification :
Bag width standard: | 12 mm or 18 mm |
Special bag width: | As per requirement |
Bag length: | min. 25 mm max. 45 mm |
Special bag length: | up to 45 mm |
Filling volume per bag: | approx. 0,2 up to 1,0 g, adjustable |
Output bags/min: | approx. (2x350)=700/min |
Number of lanes: | Independent |
Speed | 300-350 ppm |
Width of film reel: | 31 mm or 41 mm + special width |
Diameter of film reel core: | 70/76 mm |
sealing pressure: | up to 1000 N |
Air connection: | 6 bar |
Wattage: | approx. 5 KW |
Voltage supply standard: | 400V/3/N/PE/50Hz |
Protection class: | IP 54 |
Weight: | approx. 700 kg |
Color standard: | stainless steel , Silver, Red |
Packaging material: | Non woven Filter Paper, |
Technical details :
- PLC Mitsubishi Japan
- HMI Mitsubishi Japan
- Geared Motor : Lenze, Bonvario (Italian)
- A.C. Drive : Mitsubishi (Japanese)
- Pneumatic : Festo (German) , SMC (Japanese), Pneumax (Italian)
- Sensor : P&F (German)
- Temperature controller : Omron, PID (Japanese)
- Contact parts : Stainless steel 304 Food Grade
- Auto Counting system
- Conveyor system
- All Electrical Parts : Schneider (France)
Other Details
- Usage : Industrial
- Features : Long Life, easy to maintain
- Surface Treatment : Polished
- Export market: world wide
- Delivery time depend on order location
